Wood Insert Turbo 634 Supra 6 kW

Turbo 634 Supra 6kW wood insert.
The Turbo 634 Supra 6kW cast iron wood insert for the renovation of fireplaces in a fireplace or in inserts to be integrated into an existing fireplace.
EcoDesign and heating volume of 120 m2. Logs up to 50 cm.

The Turbo 634 Wood Inserthas an ingenious design suitable for open chimney installation as well as for the creation of new chimneys.
This turbo insert is incomparable in efficiency, thanks to its turbo function that distributes heat throughout the room.
With an authentic design thanks to its cast iron door, Turbo 634 can be installed without casing in open chimney renovations.
- Ideal for renovating an open fireplace.
- Large Diagonal Flame Vision 58 cm.
- Dimensions: 65 x 53x 41.5 cm.
- High-performance cast iron heating body.

The Turbo 634 Steel Wood Insert  Supra can be installed in rustic and modern interiors as well as the oldest, to elegantly enhance your home.
This rectangular insert is designed to bring a warm and comfortable atmosphere to your home for your heating.
The Supra Modern-Style Turbo 634 Cast Iron Wood Insert is made from high-quality materials, to ensure long life and optimal heating performance.

The hot fumes pass between the exchanger tubes and are evacuated directly into the drain of your old chimney; during installation, there is no connection work to the old conduit.
Switching on the manual ventilation thanks to the switch on the front of the device.
Its robust and resistant structure guarantees reliable and durable use for many years.
The sleek design of this Wood Insert is also practical and easy to use for daily or occasional heating.
Its efficient combustion system provides even, even heat, and its design allows for easy and effortless use.

Combustion and Materials :
- 2 turbines mounted in series to distribute heat in the room,
- High-performance cast iron heating body,
- Cast iron grill and hearth Silk-screened glass door,
- High-strength glass-ceramic door.

 Installation and Use :
- Unique air control for perfect combustion control,
- Connection of the fumes above (200 mm),
- Easily accessible ashtray with a large capacity to space out ash removal
- Front opening door,
- Clean glass system,
- Installation possible without open stack casing,
- Rustic style hearth plate interior to bring character to your fireplace,
- Large diagonal flame vision 58 cm (26 inches).

Characteristics:
Contemporary Wood Insert Model Turbo 634,
Indicative heating area: up to 120 in m²,
Energy class: A,
Efficiency (in %): 78,
Seasonal yield (in %): 68,
Log length (in cm): 33 to 50 max,
Width (in cm): 65,
Height (in cm): 53,
Depth (in cm): 41.5,
Power (in kW): from 3 to 10,
Product brand: SUPRA,
Commercial reference: Turbo 634,
Volume to be heated (in m³): from 60 to 120,
Installation: recessed,
Connectable directly to outside air: yes,
Connection to outside air: diameter 75mm, (rear or bottom),
Waterproof (BBC home compatible): no,
Style: Rustic,
Window position: Frontal,
Color: Black,
Material of the cladding: steel,
Heating element material: cast iron,
Interior cladding of the heating element: cast iron and vermiculite,
Finish: matt black,
Product weight: 77 kg,
Energy Type: Wood,
Loading the logs: Face,
Fire vision (diagonal): 71 cm,
Maximum log length (in cm): Up to 33 - 50 max,
Smoke Evacuation: Back and Top,
Nozzle outlet diameter (in mm): 200,
Average flue gas temperature: 242°c,
Nozzle Vacuum (Nominal): 12 Pa,
CO emission (%): 0.103) 1282,
Rated load: 1.8kg/h,
Standard: NF EN 13240,
Product Usage: Wood Heating,
Green flame: no,
Green flame energy class: 7 stars,
Eligible MaPrimeRénov: Yes,
Warranty: 2 years.

Regulations: To avoid any risk of fire, this product must be installed according to the rules of the art and in accordance with the technical rules recalled in the instructions.
It must be installed by a professional or a qualified person.
Chimney sweeping: In accordance with the regulations, chimney sweeping must be done 2 times a year, including 1 time during the heating period.
Availability period 70.2x68 x 55.5 cm, weight 92 (in kg).
